2901207957-UD 180+ High Efficiency Filter Element for Compressed Air System

Product Introduction

Downstream contamination silently degrades air quality, damaging dryers, valves, and finished products. 2901207957-UD180+ is a precision filter element tailored for the UD180+ compressed air line, commonly serving Atlas Copco and compatible systems. Positioned after the air oil separator, this cartridge captures fine solid particles and residual aerosols from the compressed air stream. Its advanced filtration media ensures clean, dry air reaches your pneumatic tools and process equipment, safeguarding production quality and reducing maintenance costs.

Running a clogged or bypassed filter forces contaminants into downstream equipment, accelerating wear on air dryers and control valves while increasing pressure drop and energy waste. Replace this element at scheduled service intervals or upon high differential pressure alarms. During installation, always verify the O-ring seal seats perfectly in the filter housing to prevent unfiltered air bypass.

Confirm housing model, flow rate, and connection size before dispatch. Service life varies with intake air quality, pre-filtration efficiency, and operating hours; the removed element and machine serial remain the ultimate fitment verification. Also called line filter element, coalescing filter, compressed air precision filter cartridge.
