2911011800 Robust Oil Stop Valve Service Kit for Portable Screw Air Compressor

Product Introduction

Shutdown backflow is the quiet troublemaker—oil creeps backward, saturates the airend, and the next startup fights its own lube circuit. 2911011800 is Atlas Copco's service kit 2911-0118-00, an oil stop / check valve kit for portable screw compressors such as XRHS, XRVS, XAH, XATS and OR-series machines . The valve lets oil or air move one way and blocks reverse flow during stop, unload, or system backpressure; the kit refreshes seals, discs, and wear parts so the stop function stays crisp instead of weeping.

A lazy seat or stuck disc shows up as oil migration after shutdown, slow pressure build, air loss at idle, or faults that get blamed on the separator. Rebuild on overhaul or at the first sign of backflow—never reuse old O-rings over the new set. Clean the bore, lay parts out in sequence, check spring and seat condition, then torque square so the body seals evenly.

Confirm machine model and serial before dispatch; portable drill-air and utility frames are not interchangeable with stationary GA kits by number alone. Also called oil stop valve kit, check valve repair kit, one-way valve service set.
