1622365600 Oil Gas Separator Cartridge with Flange Gasket for Screw Compressor

Product Introduction

Oil carry-over ruins downstream air quality, and the separator core is where that battle is won. 1622365600 is a flanged air oil separator element for oil-injected screw compressors, visually matching the coalescing cartridge style with a multi-bolt top flange, perforated outer shield, and accompanying O-rings for a sealed install. Oil-laden discharge air enters the core, fine droplets coalesce through the media, drain back to the lube circuit, and clean air exits the system. Stable differential pressure and low carry-over protect dryers, valves, and pneumatic tools downstream.

Running past service interval is the expensive option. Differential pressure climbs, oil consumption rises, and a failing element can dump oil straight into the line. Replace on service hours or at the DP alarm, and treat the scavenge return as part of the job—blockage or a cracked line causes false high carry-over even with a good cartridge. The included gaskets must seat cleanly against the flange; reused seals and uneven bolt torque remain the top cause of post-installation leaks.

Match flange hole pattern, overall height, OD, and central return tube to the removed element. Cross references vary between suppliers, so the old part and compressor tag decide the final fit. Also called oil gas separator, air oil separator element, coalescing separator cartridge, separator filter kit.
