1614905400 Wrap-Type Air Oil Separator Core for GA90 GA110 Screw Compressor

Product Introduction

Oil leaving the separator tank is lost lubricant and contaminated air at the same time. 1614905400 is a wrap-type air oil separator element for oil-injected screw compressors, cross-referenced with 2906056400 and applied on GA90/GA110/GR200-class machines in supplier listings . Glass-fiber coalescing media pulls micron oil mist out of the discharge air; separated oil drains back through the scavenge path and clean air continues downstream.

Letting it run loaded pushes differential pressure up, raises power draw, and sends oil into dryers and tools. Replace on the DP alarm or service hours, and inspect the return line while the tank is open—blocked, cracked, or wrongly set scavenge tubing causes high carry-over even with a fresh core .

Confirm flange diameter, cartridge OD, inner bore, height, and anti-static grounding against the removed element before dispatch. Service life quoted around 3500–5200h varies with oil condition, intake air, and operating temperature . Also called oil gas separator, coalescing separator cartridge, wrap separator element.
